上海翻譯公司完成智能工具說明英文翻譯
發布時間：2018-08-14 09:03 點擊：
上海翻譯公司完成智能工具說明英文翻譯
User informationPowertoolFor the VAKUUM-CUTMIX VCM 550;VCM 530 andCM 520User informationPowertoolEN_Powertool K+G Wetter_Übersetzung Originalbetriebsanweisung V1.2.docx 11.10.2011 10:57:00 Seite 20 Safety Directions The attachment tool, Powertool, enables the knife shaft to betightened or loosened safely and professionally. In addition to thespecial safety information given here, please always observe theuser information of the VACUUM-CUTMIX VCM 550, 530 and CM520 as well as that of the WMK knife head. If the machinechanges hands, this information must be passed on, too. Make sure that the cap nut of the knife head is firmly tightened! Retighten the cap nut after a long operating rest period (more than5 hours) and after changing a knife within 5 to 10 minutes ofoperating time! The plastic parts of the knife head are subject tochanges under the influence of temperature and humidity, as aresult of which the necessary tension cannot be guaranteed anymore under certain circumstances. Always tighten the cap nut after using the emergency stop buttonbecause of extreme brake force! Only use the dynamometric key supplied with the Powertool.This is adjusted to a specific torque at the factory and must not bechanged.However, if this is changed unintentionally, then always contactthe customer service department of K+G WETTER. Damaged cap nuts must either be restored to working order or, inthe case of serious defects, exchanged for new ones. Always store your Powertool in a dry place when not in use.The materials used are not universally resistant against corrosionor ageing due to functional and manufacturing reasons. If somebody is not able to read or to understand this userinformation, all instructions and safety guidelines must bescrupulously explained to him. It concerns your safety!Possible consequences for nonobservance: fatal or serious to extremely serious injuries!!! serious damage to the machine. unsatisfactory product quality.User informationPowertoolEN_Powertool K+G Wetter_Übersetzung Originalbetriebsanweisung V1.2.docx 11.10.2011 10:57:00 Seite 3Table of contents Page0 Safety Directions 21 Working with the Powertool 41.1 Protective Measures 41.2 Obligations of the Operator 41.3 Details concerning Storage 41.4 Tightening the Cap Nut 4User informationPowertoolEN_Powertool K+G Wetter_Übersetzung Originalbetriebsanweisung V1.2.docx 11.10.2011 10:57:00 Seite 41 Working with the Powertool1.1 Protective MeasuresAlways observe the safety directions and the user information of theVACUUM-CUTMIX VCM 550; 530, CM 520 and the WMK knifehead.1.2 Obligations of the OperatorThe operator must instruct the employees about the requirements forusing the Powertool in accordance with the operating manual. It isrecommended to keep written proof concerning the instructions.The operator is obliged to observe the current regulations stipulatingthe place of installation e.g.:- Obtainment of operating authority- Hygiene regulations,- Industrial safety regulations and employment disqualifications,1.3 Details concerning StorageAlways store your Powertool in a dry place when not in use.The materials used are not universally resistant against corrosion orageing due to functional and manufacturing reasons.1.4 Tightening the Cap NutLocking screw(105Nm)Locking plateCap nutFigure 1Place the locking plate (with frontal notches) in front of the knifepackage and the washers on the knife shaft.First screw on the cap nut by hand and then lightly tighten with thering spanner (Figure 2) supplied.Place the Powertool on the cap nut and turn slightly to the left, sothat the four bolts can lock into place in the notches.Tighten Powertool with the dynamometric key. When the correctUser informationPowertoolEN_Powertool K+G Wetter_Übersetzung Originalbetriebsanweisung V1.2.docx 11.10.2011 10:57:00 Seite 5tension has been reached, then a double stop signal follows (adistinct jerk and a sharp click).Very gently switch over the ratchet of the dynamometric key andrelease the tension of Powertool by a slight backward movementof the dynamometric key.Remove Powertool.Tighten locking screw (see Figure 1) in clockwise direction.Dynamometric key (105Nm)1000 4900Powertool1000 4659Figure 2Rotate knife head and cutter bowl one revolution by hand.The knives must not touch the bowl. Otherwise they must be resharpened(see user information of the knife head).世聯翻譯-讓世界自由溝通！專業的全球語言翻譯供應商，上海翻譯公司專業品牌。絲路沿線56種語言一站式翻譯與技術解決方案，專業英語翻譯、日語翻譯等文檔翻譯、同傳口譯、視頻翻譯、出國外派服務，加速您的全球交付。 世聯翻譯公司在北京、上海、深圳等國際交往城市設有翻譯基地，業務覆蓋全國城市。每天有近百萬字節的信息和貿易通過世聯走向全球！積累了大量政商用戶數據，翻譯人才庫數據，多語種語料庫大數據。世聯品牌和服務品質已得到政務防務和國際組織、跨國公司和大中型企業等近萬用戶的認可。
